計時定量油脂機組Need help choosing? Contact YU LIEN
ELECTRIC LUBRICANT PUMP F80-A
Features
- THERE ARE HAND MODE AND TIMER MODE. OPERATION IS EASY AND THE MACHINE IS LIGHT AND PORTABLE.
- GREASE LOWER LIMIT ALARM AUTOMATICALLY REPORTS THE TIMING FOR RESUPPLYING GREASE, ABSOLUTELY PREVENTING INSUFFICIENT GREASE OUTPUT.
- THE GREASE IS ISOLATED FROM AIR BY A GREASE-MOVING PLATE WHICH GUARANTEES THERE IS NO AIR INSIDE THE OUTPUT OF GREASE.
- THE GREASE CAN BE SUPPLIED EVEN DURING OPERATION, ENHANCING WORKING EFFICIENCY.
- APPLICATIONS: MINOR AMOUNT SUPPLY FOR PRODUCTION LINE.
2. GREASE LOWER LIMIT ALARM AUTOMATICALLY REPORTS THE TIMING FOR RESUPPLYING GREASE, ABSOLUATELY PREVENTING INSUFFICIENT GREASE OUTPUT.
Technical data
Specifications
| Item | Specification |
|---|---|
| POWER | AC110V-2P, AC220V-2P |
| AIR PRESSURE REQUIREMENT | 4~6 bar |
| BARREL CAPACITY | 2L |
| DELIVERY RATE | 0.001cc~1cc |
| APPLICABLE LUBRICANT | NLGI #00~#3 GREASE AND DAMPING GREASE |
| OUTPUT PRESSURE | 0~78 bar |
| WEIGHT | 17.5kg |
| SIZE | 320x260x500mm |
| APPLICABLE TEMPERATURE | -5°C ~ +50°C |
Details
